Chassis Unitised body made of stamped
plate.
Steering and suspensions Fulcrum steering tube on the front
wheel-holder hub; helicoidal spring
suspension and double-acting
hydraulic shock absorber; rear with
single chamber hydraulic shock
absorber and coaxial spring not
adjustable at preloading
Front brake Disc brake (Ø 200 mm) with
hydraulic control (lever on the far
right of the handlebar) and fixed
calliper.
Rear brake Ø110 mm drum brake
Front wheel rim Die-cast aluminium alloy; 2.50 x11"
Rear wheel rim Die-cast aluminium alloy; 3.00 x
10"
Front tyre Tubeless; 110/70-11"
Rear tyre Tubeless; 120/70-10"
Dry weight 96±4 Kg
Type approval Euro 2
Toolkit
Wrenches: one 13-21mm box-spanner; lever for box-spanner; twin screwdriver. The
tools are located under the seat in an appropriate container.
54
4 Technical data

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
