TECHNICAL SPECIFICATIONS
Engine Two-stroke, single cylinder Piaggio
Hi-PER2
Cubic capacity 49.4 cc
Petrol tank Plastic, with a capacity of ~ 9 l
(including a ~2.3 l reserve)
Bore x stroke 40 X 39.3 mm
Length 1755 mm
Width 740 mm
Maximum height 1140 mm
Wheelbase 1290 mm
Compression ratio 10,3:1
Fuel Unleaded petrol
Start-up Electrical and kick starter
Lubrication With blend and variable oil variable
according to the engine revolutions
and the throttle valve opening by
means of a pump controlled by the
driving shaft with toothed belt.
Cooling Forced-circulation air cooling.
Transmission Automatic variator CVT with torque
server.
Clutch Automatic centrifugal dry clutch
53
4 Technical data

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
