Vesper Cortex M1 User Manual

33
CLASS D DSC
DEDICATED RX
CHANNELS
1
SENSITIVITY (1% BER) -115 dBm
ADJACENT CHANNEL
SELECTIVITY
80 dB
SPURIOUS RESPONSE 70 dB
INTERMODULATION 70 dB
VHF VOICE
VHF FREQUENCY
RANGE
TX
RX
156.025–161.600 MHz
156.050–163.275 MHz
DEDICATED RX
CHANNELS
3
POWER OUTPUT 25W, 1W (High, Low)
REGIONS USA, CAN, INT
SENSITIVITY (12 DB
SINAD)
-116 dBm
ADJACENT CHANNEL
SELECTIVITY
80 dB
SPURIOUS RESPONSE 70 dB
INTERMODULATION 70 dB
SPURIOUS EMISSIONS Less than –80 dBc (at 25 W)
MAX AUDIO OUTPUT
POWER
10W, < 1% THD
SOTDMA CLASS B AIS
DEDICATED RX
CHANNELS
2
FREQUENCY RANGE 156.025 – 162.025 MHz
POWER OUTPUT 5W, 1W (High, Low)
AIS SENSITIVITY (20%
PER)
-113 dBm
ADJACENT CHANNEL
SELECTIVITY
80 dB
SPURIOUS RESPONSE 70 dB
INTER-MODULATION 67 dB
M1 GNSS
SENSITIVITY -167dBm
CONSTELLATIONS
GPS, GLONASS, Bei Dou,
Galilleo
CHANNELS 72
DIFFERENTIAL
SUPPORT
SBAS, WAAS, EGNOS
NAVIGATION RATE 10Hz
CONNECTOR SMA
CERTIFICATIONS IEC 61108
FEATURES Anti-jamming, Anti-spoong
M1 GENERAL
HUB SIZE
168 x 168 x 58.7mm
(6 5/8” x 6 5/8” x 2 5/16” )
POWER SUPPLY
9-33V. 12V: 6A max, 500mA
nom
WEIGHT 770g (1.7lb)
ENVIRONMENTAL Waterproof (IPx7)
OPERATING
TEMPERATURE
-25°C to +55°C (-13°F to
+131°F)
SUPPORTED
PROTOCOLS
AIS Class B SOTDMA,
VHF Voice, Class D DSC,
ATIS (user congurable, EU
region)
NOAA Weather (US region)
TRANSMITTER
FREQUENCY ERROR
Less than 300Hz
ANT CONNECTOR SO239
SPLITTER
Max input power 25W,
Insertion Loss RX 0dB, TX
< 2dB
SPLITTER
CONNECTOR
BNC
M1 NETWORKING
NMEA 2000 GATEWAY
1 x Isolated Micro-C male
port, AIS, GPS & MOB PGN
output, Gateway Translations
to/from NMEA 0183
NMEA 0183
1 x Isolated NMEA 0183 port,
AIS and GPS sentences,
Gateway Translations to/
from NMEA 2000, 4800 /
38400 baud
WIRELESS
Access Point for up to
10 devices, 2.4GHz,
802.11b/g/n, Integrated
Antenna, SMA-RP external
antenna port (optional)
WIRELESS SECURITY WPA2 Personal
CLOUD CONNECTIVITY
LTE-Cat1 with 3G fallback
(USA, Canada), 3G (EU,
Asia), Integrated SIM,
Integrated Antenna, SMA-RP
external antenna port.
CONTROL OUTPUTS
2 Outputs, Low side driven
(max 200mA)
AUDIO
SUPPORTED
FUNCTIONS
VHF RX, Alarms
AMPLIFIER 10W Class D, THD < 1%
SPEAKER 4 ohm
