Service Manual Indicator JIK-6 Page 3
1-
3. Product Specification Sheet
Case Shell Material
ABS plastics S/S stainless steel
Waterproof Grade
N/A IP67
Dimension
230 * 150 * 90 mm
Display
6-digit 30mm high & 3-digit 10mm
high LCD (including EL
backlight)
Unit Selection
Kg or g, lb, Taiwan jin, liang, HK jin, liang, pcs, %
Power Supply
Adaptor 9V/1A, Battery 6V/3Ah
Operating Environment
-5 ~ 40
Storage Environment
-20 ~ 60
Certification
OIML (incl. CE)
Weight (incl. battery)
Approx. 2.5kg Approx. 2.8 kg
Display-LCD
S/S flat backboard (excl. battery)
6-digit 20mm high & 3-digit 9mm high - 7-Segment display
Options
Display-LED
Power Supply Adaptor 9V/1A (battery 6V/3Ah also available for
choice)
Model Basic Model Advanced Model
Conversion Mode
∆ - Σ
Internal
Resolution Range
About 1,000,000 counts
About 5,000,000 counts
3,000d(OIML) 6,000d(OIML)
External
Resolution
Precision
Max. 30,000d(non-OIML)
Max. 60,000d(non-OIML)
Analogue/
Digital
Converter
Conversion Rate
10 times/sec.
System Linearity Error
Within 0.01% of Full Load
Zero Drift
±10 ppm/
±6 ppm/
Temperatur
e Factors
Linear Drift
±3 ppm/ ±1.5 ppm/
Circuit Voltage
5VDC ± 6%, 120mA (max. 8 * 350Ω)
Applicable Range
-2 ~ 18mV -10 ~ 40mV
2uV/d (OIML) 1uV/d (OIML)
Weight
Sensor
Input Sensitivity
Over 0.2uV/d (non-OIML)
Over 0.1uV/d (non-OIML)
Calibration Options
Unit Selection Kg, g, lb Model Code Spec.
Weight
Calibration
Setting Point
Single-point or three-
point
OP1 RELAY
Sensed Weight Selectable from 1, 2, 5
Basic/advan
ced model
OP2 RS232 (RTC)
OP3
RS232-2port
(RTC)
Advanced
model
OP4 Dual channel
To Next Page
