Service Manual Indicator JIK-6 Page 9
2-3 Weighing Capacity, Sensed Weight Setting and Weight Calibration
Step I (Enter into calibration mode)
Sealed Type
(As shown in the right figure) release the
screw
at the left back, power on while holding
down
the [CAL] key at the back by use of a tool until
CAP is shown on the lower left screen, i.e. the
scale has entered into the calibration mode.
Non- Sealed Type: Turn on the scale by holding down
key until CAP is shown on the lower left screen,
i.e. the scale has entered into the calib
ration mode.
Note: If the calibration unit, capacity, and resolution have been set, you may skip Steps II~IV and press
key to enter into Step V to perform zero point calibration.
Step II (Select Calibration Unit)
You may select calibration unit (kg, g, lb) by use of
key.
Step III (Capacity Setting)
Press
key and the flickering digit will shift to the right; press , key to set any value between
1-9; after setting, pre
ss
key to enter into the next step.
Step IV (Resolution Setting)
Press
key and the flickering digit will shift to the right; press , key to set any value between
1-9; after setting, pre
ss
key to save and show the offset-value; press the weighing pan gently, if the
value changes, it’s normal.
Note: If you don’t want to perform calibration, just power off and the setting are completed.
To Next Page
