2 Introduction
Identication of engine parts
Service side
1 Oil ller cap
2 Raw water inlet ø 20 mm
3 Raw water pump
4 Oil dipstick
5 Manual operation of fuel supply pump
6 Oil lter
7 Water separator/fuel lter drain plug
8 Water separator/Fuel lter
9 Connection for gearbox push-pull cable
10 Fuse
11 Electrical system connector box
12 Fuel return pipe connection ø 8 mm
13 Air inlet silencer
14 Water separator/fuel lter air bleed
nipple
15 Manual operation of electric stop
16 Fuel supply pipe connection ø 8 mm
17 Fuel lift pump
18 Connection for throttle push-pull cable
VD01253
