cleaved
poorly, such as
core defect,
cladding defect
or fiber
incompleteness
Left and Right
fiber head
face are
unqualified
The same as
above
Solutions refer to
the
above
Left fiber head
face is
unqualified
Left fiber head
face angle
exceeds limit
Re-cleave left fiber.
If
cutting quality is still
poor
after multiple trial ,
replace the
blade
( attention: in
【Menu】->
【Splicing Mode】->
【Surface Angle
Threshold】, head
face
angle limit can be
set)
Right fiber head
face is
unqualified
Right fiber head
face angle
exceeds limit
Solution refer to the
above
Left and Right
fiber head
face are
unqualified
Left and Right
fiber head
face angle
exceeds limit
Solution refer to the
above
Fiber Angle is not
qualified
The angle errors
of the optical
fibers on both
Replace both sides
fiber
