Take out the water supply pipe from accessory bag, connect pipe’s double ends to
the water supply valve and water faucet. First, sleeve the connector 1 to the water
faucet, then join one end of water supply pipe which has steel balls to the
connector 1(hang on this water supply pipe’s end, loose it after being connected to
the connector 1), and connect the other end which is attached with a screw to the
water supply valve, the valve also has a screw in its end, screw down the valve in
clockwise. Once finished installation, check the connect part if it is leaks or not.
you should connect the water pipes according to the diagram on the rear panel.
The flow rate of condensate water is adjustable according to customers’ need.
(Condensate flow relates to the speed of making ice)
Warning：The water used to make edible ice block must be
drinking water, furthermore, water’s temperature must be
among 0.6~32℃ and the pressure among 0.138~0.552Mpa.
5. Connect the water discharge pipe
The water discharge pipe is situated at the back of the machine, extended pipe’s
end to the sewer.
Attention：In order to keep the water discharged smoothly,
discharge pipe’s lowest point must be above the highest point of
the sewer, so to prevent the discharge water to flow back.
6. Keep the main body in level situation
Please keep the main body level to ensure the ice maker
usually works. First, screw down the two adjustable legs into
the machine’s nuts. You can adjust the two legs properly if the
main body is not level.
