VEVOR LB360TA - Basic Structure

- 7 -
A
B
C
D
E
F
G
LB360TA
560
585
910
100
1570
615
837
LB400TA
560
585
910
100
1570
615
837
LB440TA
560
585
910
100
1570
615
837
LB550TA
560
585
910
100
1570
615
837
BASIC STRUCTURE
Split type
No.
Name
No.
Name
1
Top panel
8
Ventilation window
2
Water pump
9
Water supply valve
3
Water level sensor
10
Condenser
4
Front panel
11
Fan motor
5
Control panel
12
Compressor
6
Evaporator
13
Deicing solenoid valve
7
Right panel
14
Water storage tank
