10.4 Output Data
By changing the function settings on the main unit of the balance, users can select either of the
following formats: (See “4.2 Description of Functions,” on page 13.)
10.4.1 Data Format
(1) Six-digit numeric format
Composed of 14 characters, including the terminators (CR = 0DH, LF = 0AH).
1 2 3 4 5 6 7 8 9 10 11 12 13 14
P1 D1 D2 D3 D4 D5 D6 D7 U1 U2 S1 S2 CR LF
(2) Seven-digit numeric format
Composed of 15 characters, including the terminators (CR = 0DH, LF = 0AH). A parity bit can
also be appended.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
P1 D1 D2 D3 D4 D5 D6 D7 D8 U1 U2 S1 S2 CR LF
(3) Six-digit numeric format for model provided with an auxiliary scale interval
Composed of 15 characters, including the terminators (CR=0DH, LF=0AH), with “/” added to the
left of the auxiliary-scale-interval place.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
P1 D1 D2 D3 D4 D5 D6 D7 D8 U1 U2 S1 S2 CR LF
(4) Seven-digit numeric format for model provided with an auxiliary scale interval
Composed of 16 characters, including the terminators (CR=0DH, LF=0AH), with “/” added to the
left of the auxiliary-scale-interval place.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
P1 D1 D2 D3 D4 D5 D6 D7 D8 D9 U1 U2 S1 S2 CR LF
10.4.2 Polarities (P1: one character)
P1 Code Description
+ 2BH When data is zero or positive
- 2DH When data is negative
(SP) 20H When data is zero or positive
