Vibra AJ-CESeries - 2 Names of Component Parts; Main Unit

5
2. Names of Component Parts
2.1 Main Unit
Operation keys
See page 7.
Level
For checking
the level of the
balance
Turn the adjusters
until the bubble rests
in the center of the
red circle.
A
djusters:
Total of four, one on either
side at front and rear
AC adapter
connector
Measurement
pan
Liquid-crystal
display (LCD)
See page 6.
RS232C
connector
Front View
Rear view
Calibration knob
(AJH series)
Used for span adjustment of the
balance.
