5.2. THE MOST COMMON OPTIONS
5.2.1. Remote Connections (optional)
The hydrogen generators are tted with an optional remote control feature (USB-RS232), which allows
the user to check the status of the generator from a remote position, and to start/stop the production of
hydrogen.
The contacts used in the remote control are potentially free relay contacts. The contacts can be congured
via software as normally-open or normally-closed (see the Conguration section). The maximum voltage
and current ratings for the contacts are 1A / 48V. The pin conguration of the remote connector is shown
in the table below.
Remote connector pin conguration
Pin Description
1 + 2 Start (12-30 VDC polarity not important)
3 + 4 Standby
5 + 6 Reaching external pressure
8 + 15 Rell water with a 24Vdc – 1A max valve. Needs gravity. Select “Yes” in the
rell menu
9 + 10 Low water level
11 + 12 Bad water
13 + 14 Change water
For part-numbers for the remote connector option please consult the list on page 11.
