102
Maintenance
Bevel gear - cutting unit
Changing the oil
After 10 working hours
Thereafter every 200 hours of use or once a year
Quantity of oil during oil change: 0.25 litres.
The oil is changed as follows:
> Use a suitable tool to remove the oilplug 2.
> Let the oil flow into an appropriate container.
> Allow the last of the oil to drip out of the transmission for approx.
10 - 15 minutes.
> Fit oilplug 2 and tighten it fully.
> Remove oilplug 1.
> Pour the oil through the hole where the dipstick is fitted.
> Fit the dipstick on the gear and remove the dipstick again.
> Check that the oil level is up to the “max” indication on the dipstick.
> Repeat the procedure until the correct oil level is reached.
> Fit the dipstick and fasten it.
»Lubricants« page 125
»Maintenance intervals« page 72
