40
Assembly - attachment
Connection
Hydraulic connection
The tractor must be fitted with a single-acting hydraulic outlet for the
tractor's front lift device.
Control valves
The function of the control valves is as follows:
First start-up of
machine
The initial test drive of the machine is important
When the machine is connected to the tractor for the first time it must
be test driven.
Attention to the safety instructions assures your and others personal
safety.
Failure to follow the safety instructions may result in serious injuries.
> Connect carefully the tractors PTO shaft.
> Carefully increase the speed on the PTO shaft to 1000 RPM.
> Check that the machine runs even without any vibrations.
> Return the PTO shaft to idle speed.
> Connect the tractor's hydraulic system.
> Activate the machine's hydraulic function.
> Disconnect the tractor hydraulic system.
> Disconnect the tractor shaft.
Function Valve
Raising/lowering the cutting unit single-acting
