120
Troubleshooting
PTO shaft
1
Problems with stripes are more likely to occur when mowing short,
strong, spring crops in less than ideal weather conditions.
Always begin by checking that the knives on the cutting discs are
sharp.
2
Extra equipment - page 114
Conditioning too
weak
The distance between the conditioner
plate and the rotor is too great
Move the conditioner plate closer to
the rotor
49
The rotor's Y-fingers are worn down Replace the Y-fingers 94
The rotor rpm is too low Increase the speed to 900 rpm. 50
The cutterbar gets
abnormally warm
Too much oil in the cutterbar Inspect the oil level in the cutterbar 78
Wrong oil type Change to the correct oil type 125
Fault Possible cause Remedy Page
Fault Possible cause Remedy Page
The friction clutch
on the P.T.O shaft
becomes
abnormally warm
The RPM on the P.T.O shaft is too low Check that the rotational speed of the
tractor's PTO outlet is 1000 rpm.
22
The friction discs in the clutch are worn Replace the friction discs in the clutch 110
The length of the
PTO shaft is difficult
to adjust in between
the tractor and the
machine
The PTO shaft's profile tube is dirty Take the PTO shaft apart and clean
and lubricate it
73
