Preparation
25
Changing to an anti-
clockwise direction of
rotation
The transmission's direction of rotation can be changed as follows:
> Use a suitable tool to remove the guard.
> Remove the support bolts.
> Remove the guard.
> Remove the bolts on the bracket.
Guard
Bolt
Guard
Bolt
