Maintenance
97
Transmission rotor
Safety concerning maintenance work with the transmission
When working on the transmission the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected according to
the instructions serious accidents resulting in torn off limbs can occur.
When working on the transmission:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system should be disconnected.
• The hand brake should be activated.
V-belt
After 10 working hours
Thereafter, every 40 hours
of use
»Maintenance intervals« page 72
The V-belts on the rotor must be regularly checked.
The V-belt for the rotor transmission is checked as follows:
> Use a tape measure or similar to measure the springs as shown.
> The springs are tightened with a bolt to the measurement shown.
NB
A new machine or a newly fitted V-belt should be checked after a few
hours use.
