Assembly - attachment
39
Hydraulic
Safety
Only connect the hydraulics when the system is depressurised
You should only connect the hydraulic hoses to the tractor's hydraulics
when the hydraulic system on both tractor and machine is
depressurised.
There is a risk that the machine will move unintentionally.
Unintentional movement of the machine may result in serious injuries.
Avoid mixing oil
Avoid using different tractors for the same machine.
It can lead to illegal mixing of various oil types.
Illegal mixing of various oil types can damage the hydraulic system of
the tractor.
The hydraulic system should be checked regularly
All hoses and fittings should be checked regularly for visual damage.
Hydraulic hoses also age without visual damage.
Defect hydraulic hoses can result in personal injury or fire.
Colour marking of the hydraulic connections
The hydraulic connections between the tractor and the machine must
be colour marked.
By colour marking the hydraulic connections you avoid wrong
operation of the machine.
Incorrect operation or unintentional movement of the machine may
result in serious injuries.
Connecting hydraulics
When connecting the hydraulics there is an increased risk of personal
injuries. Adherence to the above instructions will ensure your own
safety and that of others.
Failure to follow the above instructions may result in serious injuries.
Therefore, when connecting the hydraulics you should check that:
• The tractor should be equipped with a single-acting hydraulic
outlet.
• The tractor should have a minimum performance of 25 L/min at
150 bar.
Securing the hydraulics in transport position
The tractor hydraulic system must not be activated unintentionally in
transport position.
Accidental activation of the tractor hydraulic system can result in
unexpected movement.
Unexpected movement can result in injuries.
