50
Operation
Changing the roller
pressure
NB
The setting for the springs must be exactly the same on both sides of
the machine.
The roller pressure is adjusted in the following way:
Left-hand side:
> Use the appropriate tools to loosen the counter nut shown, which
is located close to the springs.
> Position a tool on the tightening surface of the spring.
> Position a tool on the tightening surface of the spindle.
> Use the tool to turn the spindle.
• Turning the spindles in a clockwise direction increases the
pressure of the rollers on the crop.
• Turning the spindles in an anticlockwise direction reduces the
pressure of the rollers on the crop.
T
IP
!
It is recommended that the springs be adjusted approximately 5 mm
at a time, after which the pressure of the rollers on the crops should
be tested.
> Tighten and secure the counter nut on the spring after the final
adjustment.
Tightening surface
Tightening surface
