Maintenance
83
Bevel gear - cutting unit
Checking the oil level
Every 40 hours of use
NB
The machine must be horizontal.
The oil level is checked as follows:
> Remove the dipstick.
> Check that the oil level is up to the “max” indication on the dipstick.
NB
The oil level must always be between “min” and “max” as shown on
the dipstick.
When topping up, do the following:
> Pour the oil through the hole where the dipstick is fitted.
> Fit the dipstick on the gear and remove the dipstick again.
> Check that the oil level is up to the “max” indication on the dipstick.
> Repeat the procedure until the correct oil level is reached.
> Fit the dipstick and fasten it.
»Lubricants« page 128
»Maintenance intervals« page 73
