Maintenance
85
Arm
Every month
The oil level is checked as follows:
> Remove oilplug 3.
> Check that the oil level reaches the hole.
> When topping up, fill the oil through the hole for oilplug 3.
• The correct oil level is reached when the oil reaches the edge of
the hole for oilplug 3.
> Fit oilplug 3 and tighten it.
»Oil for cutterbar« page 128
»Maintenance intervals« page 73
