Maintenance
93
Universal joint
Safety concerning maintenance work on the cutterbar
When working on the cutterbar, the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected following the
instructions, serious accidents causing damage to limbs can occur.
When working on the cutterbar:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system should be disconnected.
• The hand brake should be activated.
Every month
»Maintenance intervals« page 73
The universal joint between the transmission and the cutterbar is
checked in the following way:
> Open the first guard.
> Use a suitable tool and remove the guard around the cutterbar's
transmission.
