Maintenance
116
Universal joint
Safety concerning maintenance work on the cutting unit
When working on the cutting unit the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected following the
instructions serious accidents causing damage to limbs can occur.
When working on the transmission:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The tractor's PTO must be disconnected.
• The tractor hydraulic system must be disconnected.
• The hand brake must be activated.
Every month
»Maintenance intervals« Page 84
The universal joint between the transmission and the cutterbar is
checked in the following way:
Remove the linchpins shown here.
Open the first guard.
Suspend the guard in the chain as shown.
Activate the tractor hydraulics and raise the machine's cutterbar
fully.
