Maintenance
126
 Use a tape measure or similar to measure the springs as shown.
 The springs are tightened with a bolt to the measurement shown.
A new machine or a newly fitted V-belt should be checked after a few
hours use.
 Fit the guard.
V-belt
Bolt
75 mm (3”)
Bolt
