Maintenance
151
Fit the knife and bolt on the new cutting disc.
Tighten up the bolt with a torque wrench to the torque shown.
Apply Loctite 242 or a similar product to all bolts.
Fit the cutting disc on the cutterbar.
Use a torque wrench to tighten the bolt to the torque shown.
Open the mechanical safety valve.
95 Nm +/- 5
70 ft/lb. +/- 3
Bolt
Loctite
242
80 Nm +/- 5
59 ft/lb. +/- 3
Loctite 242
Bolt
