Vicon Extra 832R PRO - Page 25

About the machine
25
Dim. Unit 832R PRO 835R PRO
A mm (’-’’) 5650 (18' 6'') 5650 (18' 6'')
B mm (’-’’) 5600 (18' 4'') 5600 (18' 4'')
C mm (’-’’) 350 (1' 2'') 350 (1' 2'')
D mm (’-’’) 3050 (10') 3050 (10')
E mm (’-’’) 1400 (4' 7'') 1400 (4' 7'')
F mm (’-’’) 3200 (10' 6'') 3500 (11' 6'')
G mm (’-’’) 2400 (7' 10'') 2800 (9' 2'')
H mm (’-’’) 675 (2' 2'') 675 (2' 2'')
I mm (’-’’) 3750 (12' 4'') 4150 (13' 7'')
J mm (’-’’) 1700 (5' 7'') 1700 (5' 7'')
K mm (’-’’) 425 (1' 5'') 425 (1' 5'')
