Operation
70
Adjust the cutting unit's downward pressure for both springs.
Secure the counter nuts with the springs on both sides of the
machine.
Check by lifting the cutting unit by hand, gripping both sides of the
cutting unit in the places shown.
When checking the suspension, position yourself in front of the cutting
unit and lift the cutting unit up as shown.
The weight on both sides of the cutting unit must be approximately 40-
60 kg (90-130 lb) when lifting by hand.
