Maintenance
97
Locate the oilplug on the left side of the cutterbar and remove it.
• With warm oil: Wait approximately 3 minutes
• With cold oil: Wait approximately 15 minutes.
Check the oil level as shown and refill if necessary.
• Min. 6 mm (
1
/
4
’’)
• Max. 9 mm (
3
/
8
’’)
»Lubricants« Page 177
Fit the oilplug and tighten it fully.
Open the mechanical safety valve.
Close the front guard.
Fit the linchpin.
