Digital multimeter
14 / 25
measurement can let such buttons as “RANGE”, “MAX/MIN”, “HOLD” re-get function controlling.
2． In case “OL” is displayed on the LCD, it indicates the current being
measured has exceed the current range, and please select higher
range for measurements.
Caution:
a）At the 10A range, current bigger than 10A cannot be measured,
and at mA mode, the current bigger than 600 mA cannot be
measured. Otherwise this will lead to the burning of the fuse or
damage the instrument.
b) When the testleads plugged in the input terminal of the current,
it is strictly prohibited to have the testlead connected in parallel
on any circuits.
The maximum input current: 10A (not exceeding 15s))
Overload protection: 0.6A/250V fuse ; 10A/250V fuse
× Ô¶ ¯Ê ¶± ð½ »Ö ±
Á ÷µ çÁ ÷Ñ ¡Ô ñ¼ ü
AC/
EF
DC/
Hz
× Ô¶ ¯Ê ¶± ð½ »Ö ±Á ÷
µ çÁ ÷10AÑ ¡Ô ñ¼ ü
AC/
EF
DC/
Hz
