Range
Accuracy
Resolution
600mV
±(1.6%+ 10d )
0.1mV
6V
±(0.8%+ 10d )
1mV
60V
10mV
600V
100mV
750V
±(1.0%+10d )
1V
Input impedance: 10MΩ. Overload protection：DC 1000V or AC 750V peak value
Display： Mean value response（calibrated with sine wave）.
Frequency response： 600mV: (40-100)Hz. 6V-750V: (40－400)Hz
X. DC Current (DCA)
1．Put the black testlead into the “COM” terminal and the red testlead into the “mA” or “10A” terminal.
Trigger the “ “ button or “ “ button, select automatic identification ACA/DCA measurement,
and at this time such buttons as “RANGE”.“MAX/MIN”.“HOLD” do not have the controlling functions,
and only when the “SELECT” button is pressed again to select automatic range AC or DC current
