Victor VC70D - IX. AC Voltage (ACV) Measurement; AC Voltage Measurement Procedure

Digital multimeter
1 1 / 25
Range
Accuracy
Resolution
600mV
±(0.5%+4 d )
0.1mV
6V
1mV
60V
10mV
600V
100mV
1000V
±(1.0%+6 d )
1V
Input impedance: 600mV range > 60MΩ，the others are 10MΩ.
Overload protection：DC 1000V or AC 750V peak value
IX . AC Voltage (ACV)
1． Trigger “AC/DC/EF”, at this time it is at the AC/DC voltage automatic identification mode, and
respectively plug in the red and black testleads into the holes of “VΩHz”and“COM”, as shown in the
following diagram.
2． The initial state of the meter is the AC/DC voltage automatic identification mode and a symbol of “SCAN”
is displayed; at this time, such buttons as “RANGE”.“MAX/MIN”.“HOLD” have no controlling functions,
