DENOTATIONS:
OVS – system symbol
0x – system number
A, B, CHROMO – system variant
where:
A – underwater lighting system
B – air massage system with efficiency regulation
CHROMO – chromotherapy system
A bath as a device of substantial power – frequently exceeding 2kW – must by
powered from a separate, independent circuit, protected with an vercurrent switch
according to the table
of pole number equal = number of phases + N
All baths must be connected with use of a differential switch of In=0,03A.
It can be realised as overcurrent switch with differential module.
Power supply from 2 or accordingly 3 phases is preferable in all systems where it is possible (c.f. table)
– they can be also connected into existing one-phase installations ( but this is not recommended by
producer TECHNIC INDUSTRY, due to too high power ) – by connecting phase wires of bath
power lead with phase wire of power lead – accordingly higher overcurrent protection must be
applied.
10
ENGLISH
2
5 x 2,5 mm
6900 W
TORNADO SMS
LANZAROTE, SINGAPORE
2
5 x 2,5 mm
9100 W
TORNADO SMS WITH A
HEATER 6000W
2
5 x 2,5 mm
10200 W
TORNADO SMSWITH A
HEATER 6000W
LANZAROTE, SINGAPORE
C25 / PHASE
3 PHASES
2
5 x 2,5 mm
5800 W
TORNADO SMS
C16 / PHASE
2 PHASES
2
4 x 2,5 mm
L1+L3 / C20
L2 / C16
SYSTEM
MAXIMUM
POWER
CONNECTION
METHOD
POWER LEAD
in electric
installation
OVERCURRENT
PROTECTION
C16 / PHASE
C16 / PHASE
3 PHASES
3 PHASES
3 PHASES
