14. Technical Specifications
24/3000/70-32 48/3000/35-32 48/5000/70-50
INVERTER/CHARGER
PowerControl & PowerAssist Yes
Transfer switch 32 A 32 A 50 A
Maximum AC input current 32 A 32 A 50 A
Auxiliary output Yes (32 A)
INVERTER
Input voltage range 19 - 33 V 38 – 66V
Output 1) Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0,1% (1)
Cont. output power at 25°C (2) 3000 VA / 2400 W 5000 VA /4000 W
Cont. output power at 40°C / 65°C 2200 W / 1700 W 3700 W / 3000 W
Maximum apparent feed-in power 2500 VA 4000 VA
Peak power 5500 W 9000 W
Maximum efficiency 94% 95% 96%
Zero load power 13 W 11 W 18 W
Zero load power in AES mode 9 W 7 W 12 W
Zero load power in Search mode 3 W 2 W 2 W
CHARGER
AC Input Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz
Charge voltage 'absorption' 28.8 V 57.6 V
Charge voltage 'float' 27.6 V 55.2 V
Storage mode 26.4 V 52.8 V
Maximum battery charge current (3) 70 A 35 A 70 A
Battery temperature sensor Yes
GENERAL
Programmable (AUX) relay (4) Yes
Auxiliary power supply 12V / 100mA
Programmable open collector output 70V / 100mA
Analog-digital aux inputs Yes, 2x
Temperaure sensor Yes
Voltage sense contacts Yes
Protection (5) a - g
VE.Bus communication port For parallel and three phase operation, remote monitoring and system integration
General purpose com. port Yes, 2x
Interfaces BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi
External AC current sensor (optional) 50 A 100 A
Remote on-off Yes
Operating temperature range -40 to +65 °C (fan assisted cooling)
Humidity (non-condensing) max 95%
ENCLOSURE
Material & Colour Steel, blue RAL 5012
Protection category IP22
Battery-connection M8 bolts
230 V AC-connection Screw terminals 13 mm2 (6 AWG)
Weight 19kg 30kg
Dimensions (hxwxd) 506 x 275 x 147 mm 565 x 323 x 148
STANDARDS
Safety EN-IEC 60335-1, EN-IEC 60335-2-29
Emission / Immunity EN55014-1, EN 55014-2 EN-IEC 61000-3-2, EN-IEC 61000-3-3
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Uninterruptible power supply IEC 62040-1
Anti-islanding Please consult the certificates on our website.
