19617-001 Rev. H DiagnosticPRO Edge User’s Guide 15
3. Slide the exit tray into the digitizer, keeping it high, then drop it down and slide it
back toward you so the notches fit over the internal pins.
Notch Internal pin
4. When properly positioned, the exit tray will protrude a small distance from the
digitizer, and it can’t be pulled out without lifting it off the internal pins.
Exit tray in position
