PAGE 17 of 40 GSM DOOR INTERCOM TECHNICAL MANUAL VER 2.0.8
PROGRAMMING BY TEXT MESSAGE
Programming by text message is a simple way to customise the settings of the intercom
panel and add or delete telephone numbers. If you have a large number of buttons or
telephone numbers to enter you may find programming easier with the PC software.
Simply send texts in the format below to the telephone number of the SIM within the
intercom panel:-
<4 DIGIT CODE><3 DIGIT FUNCTION CODE><OPTIONAL DATA><OPTIONAL ?>
4 DIGIT CODE: The code prevents unauthorised access to the programmable
features of the system. The code must be four digits long but can be
any combination using digits 0 – 9. The default code is 1111 and will
be used for all examples in this manual.
3 DIGIT FUNCTION CODE: The 3 digit function code identifies the programmable feature
to be changed. The code must be in capital letters. The table
below lists the available codes.
DESCRIPTION CODE EXAMPLE SETTINGS DEFAULT PAGE
Store a primary telephone no. STN 1111STNnnn”01912243174” nnn = 001-050 N/A 18
Store a divert telephone no. STD 1111STDnnn”01912241559” nnn = 001-050 N/A 18-19
Store a dial to open no. STR 1111STRnnn”07771234567” nnn = 001-250 N/A 18
Set call time SPT 1111SPTnn nn = 01 - 12 02 (40s) 19
Set relay time RLT 1111RLTnn nn = 00 - 99 05 (5s) 19
Set auxiliary out time AOT 1111AOTnn nn = 00 - 99 05 (5s) 20
Set auxiliary out mode AOM 1111AOMnn nn = 00 or 01 01 20
Keep connection facility NOD 1111NODnn nn = 01 - 99 0 (Disabled) 20-21
Divert to second no. time DIT 1111DITnn nn = 01 - 99 15 (15s) 21
Check GSM signal strength SIG 1111SIG? N/A N/A 29-30
Check software version VER 1111VER? N/A N/A 29
Dial a number DLE 1111DLE”123” N/A N/A 21
Store SMS message for g-4 SMS 1111SMS”HouseAlarm” N/A AUX TRIG 21
Change 4 digit code CDE 1111CDE1234 Any 4 digits 1111 20
Initiate a special command PRG 1111PRG(command) AT commands N/A 22
Trigger the relay RLY 1111RLY N/A N/A 29
Trigger the auxiliary output AUX 1111AUX N/A N/A 29
Store balance check dial string SDL 1111SDL”*#1345#” N/A N/A 22
Check credit balance BAL 1111BAL? N/A N/A 29-30
Latch the relay RLA 1111RLA N/A N/A 29
Unlatch the relay RUL 1111RUL N/A N/A 29
Latch the auxiliary output ALA 1111ALA N/A N/A 29
Unlatch the auxiliary output AUL 1111AUL N/A N/A 29
Store the master telephone no. STM 1111STM”07771234567” N/A N/A 22
Store time band TBA 1111TBA”06002300” HHMMHHMM 00002359 22-23
Check intercoms time & date CLK 1111CLK? N/A N/A 29
Input status check CHK 1111CHK? N/A N/A 14
Silent dialling mode AUE 1111AUEnn nn = 00 or 01 01 23
Enable additional diverts EXD 1111EXDnn nn = 00 or 01 01 24
Send tone after answer (But 1) DTP 1111DTPn n = 0 – 9 or X X 23
Send tone after answer (Div 1) DTD 1111DTDn n = 0 – 9 or X X 23
Send DTMF tone delay DTT 1111DTTnn nn = 01 – 12 03 23
OPTIONAL DATA: The optional data will vary depending on the command used. It may be a telephone
number, a time setting or may not be used at all. For more information see the
command settings below.
