Videx VX2300 User Manual

VX2300 2 Wire Video Digital System
PrtCode:VX2300_2_9.doc – Pag.7 08/03/2011 Rev.2.9
Test Mode: Error Codes Table
Code Message / Description
1 Called User not available in the system: the device related to the user is not recognized in the system
2 Called User is present but does not answer: the device related to the user is recognized in the system but does not answer
3 Other transmissions recognized on the BUS: because of an intercommunicating conversation or a call from another door panel.
4 Called User in privacy mode: the intercom/videophone called is in “privacy” mode.
5 The end of conversation is not recognized: The intercom/videophone related to the user does not recognize the end of conversation
TO SET MAIN CAMERA
To set the main camera, operate the switch 1 on the two way dip-switch bank
Switch Position Description
ON
2
1
=OFF
=ON
ON
SW
The main camera is the door panel built-in camera: during a call or a camera recall the video shown by the monitor is the video com-
ing from the door panel built in camera. To switch to the external camera (if connected) operate the videophone proper button.
ON
2
1
=OFF
=ON
ON
SW
The main camera is the external camera: during a call or a camera recall the video shown by the monitor is the video coming from the
external camera. To switch to the door panel built-in camera operate the videophone proper button.
SPECIFICATION
Housing/Mounting
Size of two modules 4000 Series / 4000 Series Modular System
Push Buttons
12 buttons Keypad
Programming
Yes, carried out through the panel keypad or via PC through serial RS-232 connection
Controls
Yes, balance trimmer plus microphone, loudspeaker volume trimmer
Interfaces
Yes, one serial RS-232 interface for pc connection
Memory
Yes, can be stored up to 250 users for a maximum of 100 flats
Power Supply
Supplied by the bus
Working Temperature
-10 +50ºC
CUSTOMER SUPPORT INFORMATION
All Countries Customers UK Customers
VIDEX Electronics S.p.A.
www.videx.it – technical@videx.it
Tel.+39 0734 631669
Fax +39 0734 632475
VIDEX Security LTD
www.videx-security.com
Tech Line 0191 224 3174
Fax 0191 224 1559
The product is CE marked demonstrating its conformity and is for distribution within all
member states of the EU with no restrictions.
This product follows the provisions of the European Directives
89/336/EEC & 92/31/EEC (EMC),
73/23/EEC (LVD) and 93/68/EEC (CE marking).
Il prodotto è marchiato CE a dimostrazione della sua conformità e può essere distribuito
liberamente all’interno dei paesi membri dell’unione europea EU.
Questo prodotto è conforme alle direttive Europee
89/336/EEC & 92/31/EEC (EMC),
73/23/EEC (LVD) e 93/68/EEC (Marcatura CE).
