Viessmann B2HA 80 - Frame Mounting

Vitodens 200-W B2HA 80 to 100, 285 to 352 Installation
5685 827 - 14
16
Frame Mounting
Boiler Connections
The boiler stand is used for free-standing installation of
a single boiler within the mechanical room.
When using the boiler stand, ensure that the stand is
securely fastened to the floor (recommended concrete
expansion anchors are Hilti model KB-TZ e x 4 or
equivalent.
a in. (mm)
19f (500)
b in. (mm)
76c!b (1950!12.7)
c in. (mm)
63!b (1600!12.7)
d in. (mm) 22 (560)
e in. (mm) 24 (610)
Vitodens 200-W
B2HA 80 to 100, 285 to 352
a *1 in. (mm)
34a (870)
b *1 in. (mm)
79b (2020)
c in. (mm) 23 (585)
d in. (mm)
5d (130)
*1 ! b in. (12.7 mm) for adjustment of the levelling feet.
