106
Rated voltage 230 V
Rated frequency 50 Hz
Protection class I
Permissible ambient temper-
ature
■
Operation 0 to +40 °C
■
Storage and transport -20 to +65 °C
Backup fuse (power supply) max. 16 A
Rated heating output range
P
cond
: T
F
/T
R
= 50/30 kW 16 - 80 32 - 120 32 - 160 48 - 200 48 - 240 64 - 280 64 - 318
P
n
: T
F
/T
R
= 80/60 kW 15 - 74 29 - 110 29 - 146 44 - 184 44 - 220 58 - 258 58 - 291
Rated heat input kW 76 113 151 189 226 264 300
Product ID CE-0085CR0391
Permiss. operating tempera-
ture
°C 95
Permiss. flow temperature
(= safety temperature)
°C 110
Max. permiss. operating pres-
sure
bar 6
MPa 0.6
Min. permiss. operating pres-
sure
*2
bar 1
MPa 0.1
Test pressure bar 7.8
MPa 0.78
Boiler body dimensions
Length mm 665 770 770 890 890 1004 1004
Width mm 680
Height mm 1650
Total dimensions incl. casing,
boiler flow and return; excl. boil-
er flue connection
Length mm 739 862 862 967 967 1085 1085
Width mm 750
Height mm 1650
Foundation dimensions
Length mm 750 850 850 1000 1000 1100 1100
Width mm 800 800 800 800 800 800 800
Height mm 100 100 100 100 100 100 100
Weight
Overall unit weight kg 238 295 295 340 340 385 385
Packed unit kg 288 345 345 390 390 435 435
Boiler body kg 183 230 230 265 265 300 300
Boiler body with transport pallet kg 210 260 260 295 295 330 330
Burner kg 10 11 11 15 15 15 15
Water capacity l 65 103 103 145 145 180 180
*2
The minimum operating pressure is essential for safe operation. It can be ensured with a minimum pressure switch (1 x per
system for multi boiler systems)
Specification
Vitocrossal specification
5839829
Appendix
