exit menu
Call up the relevant track
diagram to select track
sections. Interconnection
of different track diagrams
in order to dene starting
point and destination
is possible.
Show again the menu of
the index card.
Go through the index cards one after
another and make the respective entries in
order to set up and to edit a route.
Index card 1 and 2:
• Enter the route number and the
explanatory comment using the alpha-
numeric screen keyboard.
• Select the operating mode
(automatic or manual operation)
• Dene the starting point and the
destination on the track diagram (optio-
nal). Touch one of the index card-selec-
tion elds (previous or next index card).
After that a track diagram opens up.
• Choose the appropriate track diagram.
• Touch the respective symbol eld you
want. The chosen symbol eld shows a
green twinkling frame.
• Return to the index card.
Index card 3:
You can call up a route either by feedback
modules or time controlled. In order to do
that, press the desired touch eld. On the
track diagram you select the feedback
modules you take into consideration for an
automatic call up of the route.
In case that a passing train activates the
respective feedback module the Comman-
der can automatically switch over and
open the proximate route, if it is not
occupied. Using intelligent feedback
modules the route control can also be
activated in dependence of a special train.
Index card 4:
Enter all feedback sections belonging to
a route into the index card “respect feed-
back”. This way you ensure that a route is
only switched and unlocked, if the
respective sections are really free.
Index card 5:
You enter all commands that are necessa-
ry for the operations on the route in the
index card “control commands”. This inclu-
des the switching of turnouts and signals
belonging to the route but also the driving
behaviour of the train.
You select the turnouts and signals in the
track diagram. Touch the respective
