2.2 Specification
Specification
Boiler type Pyromat ECO... 35 45 55 65 61 81 101 151
Part no. PMEA001 PMEA00
2
PMEA00
3
PMEA00
5
PMEA00
4
PMEA006 PMEA00
7
PMEA008
Rated heating output kW 40 50 60 75 85 100 120 170
Minimum heat consumption, wood kW 35 38 45 55 60 75 90 110
Max. log length m 0.5 0.5 0.5 0.5 1 1 1 1
Hopper capacity l 185 185 255 255 375 375 500 500
Boiler water content l 130 130 170 170 230 230 300 300
Boiler weight (dry) kg 750 760 920 935 1300 1320 1680 1720
Test pressure bar 6 6 6 6 6 6 6 6
Max. operating pressure bar 3 3 3 3 3 3 3 3
Max. boiler water temperature, wood °C 100 100 100 100 100 100 100 100
Min. return temperature °C 70 70 70 70 70 70 70 70
Pressure drop, water side (diff. 10 K) mb
ar
32 32 62 62 56 56 112 112
Pressure drop, water side (diff. 20 K) mb
ar
8 8 16 16 14 14 28 28
Thermally activated safety valve: min.
flow rate at 2.5 bar
kg/
h
2000 2000 2800 2800 3500 3500 5500 5500
Boiler efficiency
(rated heating output, wood)
% 92 92 92 92 92 92 92 92
Flue gas temperature (rated heating
output, wood)
°C 180 180 180 180 180 180 180 180
Flue gas mass flow rate
(rated heating output, wood)
g/s 30.4 35.2 44 56 58.4 72 88 108
Max. draught, wood
*1
Pa 25 25 25 25 25 25 25 25
Rated heating output, oil kW 35 38 45 55 60 75 90 110
Boiler efficiency
(rated heating output, oil)
% 87 87 87 87 87 87 87 87
Flue gas temperature
(rated heating output, oil)
°C 168 168 168 168 172 172 168 168
Required chimney draught
*2
Pa ±0 ±0 ±0 ±0 ±0 ±0 ±0 ±0
Electrical output, flue gas fan W 80 80 80 80 150 150 250 250
Return temperature raising facility
with buffer cylinder control valve
Boiler pump Wilo Typ
e
RS 30/6 RS 30/6 TOP-S
30/7 EM
TOP-S
30/7 EM
TOP-S
30/7 EM
TOP-S
30/7 EM
TOP-S
40/7 EM
TOP-S
40/7 EM
Electrical output, pump W 46 - 93 46 - 93 85 - 195 85 - 195 85 - 195 85 - 195 220 - 390 220 - 390
Pump output
m
3
/
h at
mW
C
2.5 at 6.5 2.5 at 6.5 7.5 at 7.0 7.5 at 7.0 7.5 at 7.0 7.5 at 7.0 16.5 at
7.0
16.5 at 7.0
Boiler control valve Siemens Typ
e
VXG
48.32
VXG
48.32
VXG
48.32
VXG
48.32
VXG
48.40
VXG
48.40
VBF
21.50
VBF 21.50
Drive, boiler control valve Siemens SSY 319 SSY 319 SSY 319 SSY 319 SSY 319 SSY 319 SQK
21.50
SQK
21.50
Siemens buffer cylinder control valve Typ
e
VXG
48.32
VXG
48.32
VXG
48.32
VXG
48.32
VXG
48.40
VXG
48.40
VXG
48.40
VXG
48.40
Drive for Siemens buffer cylinder con-
trol valve
SSY 319 SSY 319 SSY 319 SSY 319 SSY 319 SSY 319 SSY 319 SSY 319
Weight of return temperature raising
facility with buffer cylinder control
valve
kg 14 14 16 16 20 20 40 40
Weight, cylinder control valve kg 2.5 2.5 2.5 2.5 2.5 2.5 6.9 6.9
Connections
Flue gas connection DN
200
*3
200
*3
200
*3
200
*3
200 200 250 250
Drain R ½ ½ ½ ½ ½ ½ ½ ½
Boiler return R 1¼ 1¼ 1¼ 1¼ 1½ 1½ 1½ 1½
Boiler flow R 1¼ 1¼ 1¼ 1¼ 1½ 1½ 1½ 1½
Safety connection R ½ ½ ½ ½ ½ ½ ½ ½
Temperature sensor R ½ ½ ½ ½ ½ ½ ½ ½
Sight glass R 1 1 1 1 1 1 1 1
*1
Maximum overpressure in the start phase (chimney cold) in the flue pipe downstream of the flue gas fan
*2
No secondary air device (draught limiter) required
*3
Reduction to DN 160 or DN 180 possible
Pyromat ECO
(cont.)
PYROMAT ECO
9
5822 546 GB
