6.1 DHW cylinder Vitocell 100-V
DHW cylinder Vitocell 100-V
DHW cylinder Vitocell 100-V
Cylinder capacity (litres) 160 200 300 500 750 1000
Part no. 3003702 3003703 Z002575 Z002576 Z004044 Z004045
Delivered condition
Vitocell 100-V, type CVA
160, 200 and 300 litre capacity
DHW cylinder made from steel with Ceraprotect enamel coating for
DHW heating.
■ Welded-in sensor well for cylinder temperature sensor or thermo-
stat
■ Adjustable feet
■ Protective magnesium anode
■ Fitted thermal insulation
Colour of the epoxy-coated sheet steel casing: Vitosilver.
DHW cylinders with 160, 200 and 300 litre capacity are also available
in white.
Vitocell 100-V, type CVA
500 litre capacity
DHW cylinder made from steel with Ceraprotect enamel coating for
DHW heating.
■ Welded-in sensor well for cylinder temperature sensor or thermo-
stat
■ Adjustable feet
■ Protective magnesium anode
Packed separately:
■ Removable thermal insulation; the colour of the plastic-coated ther-
mal insulation is Vitosilver
Vitocell 100-V, type CVA
750 and 1000 litre capacity
DHW cylinder made from steel with Ceraprotect enamel coating for
DHW heating.
■ Thermometer
■ Welded-in sensor well for cylinder temperature sensor or thermostat
■ Adjustable feet
■ 2 protective magnesium anodes
Packed separately:
■ Removable thermal insulation; the colour of the plastic-coated ther-
mal insulation is Vitosilver
Specification
For DHW heating in conjunction with boilers and district heating sys-
tems, as option with electric heater as accessory for DHW cylinders
with 300 and 500 l capacity.
Suitable for the following systems:
■ DHW temperatures up to 95 °C
■ Heating water flow temperature up to 160 °C
■ Operating pressure on the heating water side up to 25 bar
(2.5 MPa)
■ Operating pressure on the DHW side up to 10 bar (1.0 MPa)
Cylinder capacity l 160 200 300 500 750 1000
DIN register number 9W241/11–13 MC/E
Continuous output
For DHW heating from 10 to 45 °C
and a heating water flow tempera-
ture of ... at the heating water
throughput stated below
90 °C kW 40 40 53 70 123 136
l/h 982 982 1302 1720 3022 3341
80 °C kW 32 32 44 58 99 111
l/h 786 786 1081 1425 2432 2725
70 °C kW 25 25 33 45 75 86
l/h 614 614 811 1106 1843 2113
60 °C kW 17 17 23 32 53 59
l/h 417 417 565 786 1302 1450
50 °C kW 9 9 18 24 28 33
l/h 221 221 442 589 688 810
Continuous output
For DHW heating from 10 to 60 °C
and a heating water flow tempera-
ture of ... at the heating water
throughput stated below
90 °C kW 36 36 45 53 102 121
l/h 619 619 774 911 1754 2081
80 °C kW 28 28 34 44 77 91
l/h 482 482 584 756 1324 1565
70 °C kW 19 19 23 33 53 61
l/h 327 327 395 567 912 1050
Heating water throughput for the stated con-
tinuous outputs
m
3
/h
3.0 3.0 3.0 3.0 5.0 5.0
Standby heat loss q
BS
at a temp. differential of 45 K (actual values to
DIN 4753-8).
kWh/
24 h
1.50 1.70 2.20 2.50 3.50 3.90
Dimensions
DHW cylinder
PYROMAT ECO
37
5822 546 GB
