Wiring diagram for porthole
5777744-03 GB Subject to technical changes!
15 Wiring diagram for porthole
230 V AC 50 Hz
mains connection
PE N L1
PE
T
L1
4
N
Thermostat L1-4 only if heater is present
BN
BN
BU
BU
Junction box
Frame
heater
Frame
heater
(optional)
5246454-08
