Viessmann TectoCell Standard Plus 80 User Manual

9
Assembly
5777744-03 GB Subject to technical changes!
 Drill a hole into the plate end of the opposing ele-
ment (6)throughtheholeprovided(7)intheplate
surface of the spring side.
 Rivettheoverlappingoftheoorelements.
Drill holes
 Use a suitable lubricant for drilling.
L
Depending on the oor, make the drill holes according
to the specications below.
1600Noor:
 Drill with Ø 3.3 mm
 Drill hole at least 10 mm deep.
 Pop rivet with Ø 3.2 mm
 Hand riveter with mouthpiece (suitable for stain-
lesssteel)for3.2mmpoprivet
3000N,4000Nand5000Noor:
 Drill with Ø 5.0 mm
 Drill hole at least 24 mm deep.
 Countersunk rivet with Ø 5.0 mm
 Hand riveter with mouthpiece (suitable for stain-
lesssteel)for5.0countersunkrivet
4.7 Seal operating apertures in the cam locks in
the oor elements
L
Using a steel hammer will run the risk of contamina-
tion with outside rust.
Â
1
2
3
4
Fill operating aperture (3)withthesuppliedheat
insulationfoamller(4).
 Fill the operating aperture (3)bysprayingitwiththe
enclosed sealant (2).
 Seal operating apertures (3)withplugs(1).
L
Use suitable plugs depending on the oor.
1600Noor:
 Plug Ø 15.0 mm stainless steel
3000N,4000Nand5000Noor:
 Plug Ø 15.1 mm stainless steel, knurled
4.8 Assembling wall elements
Â
Makesurethattheinneroorpanelisfreeofgrease
and dust in the area of the inner wall panel (2).
