Viessmann TectoCell Standard Plus 80 User Manual

6
Assembly
5777744-03 GB Subject to technical changes!
Conditions for installation space
 Do not install TectoCell cold rooms and deep-freez-
ing rooms near heat sources.
 Avoid direct sunlight.
 Makesurethattheinstallationspaceissufciently
ventilated in order to discharge any heat that builds
up.
 Distance from TectoCell cold rooms and deep-freez-
ing rooms to building wall and ceiling:
 Room temperature in positive range:
at least 50 mm
 Room temperature in negative range:
at least 100 mm
 The distance from the room to the wall must be
ensured with suitable spacers, since the room’s
position may slip depending on the load it is
under!
 Observespecicationsonthenecessaryclearance
above the TectoCell cold rooms and deep-freezing
rooms in the operating instructions of the unit in
question.
 Observeasuitableinstallationheightforoorprop
designs and add to it if necessary.
Conditions for outdoor installation
 Make sure that the TectoCell cold rooms and deep-
freezing rooms is not exposed to the effects of
weathering (snow loads, rainwater, wind pressure,
etc.).
 Make sure that local and on-site construction
measures to protect from the effects of weather-
ing have been completed before installing the
Tecto cold rooms and deep-freezing rooms.
 Observe national and local rules on work safety and
accident prevention measures.
 Observe local regulations on operation and mainte-
nance.
4.2 Before installation
 Makesurethattheoorislevel.
 Levelunevenoor(sieheKap.„4.3Bodenausglei-
chen“aufSeite7).
 Contact Viessmann if it is not possible to comply
with national and local regulations.
 Carefully remove the elements and accessories.
 Pre-sort the elements and accessories.
 Draw the footprint of the room on the installation
oorusingasuitableimplement.
4 Assembly
DANGER!
Risk of death due to electric
shock!
f Do not conduct any mechanical
work
(suchasdrillingorsawing)onthe
inside or outside of the door or
porthole (see Chap. “4.19 Mechani-
cal work on the door or porthole” on
page13).
NOTE
Damage due to improper han-
dling!
f Ensurethatthesealprolesof
the elements are not damaged.
NOTE
Damage due to improper trans-
port!
f Only carry room elements from
the bottom to prevent panels from
separating.
NOTE
Damage due to improper mount-
ing!
f Make sure that room elements
are correctly mounted after assem-
bly.
NOTE
Damage due to improper mount-
ing!
f Make sure that all preparatory
work for mounting units to the ele-
ments.
f Observe unit instructions.
4.1 Installation conditions
NOTE
Damage due to condensation
water!
f Make sure that the installation
roomissufcientlyventilated.
f Make sure that all necessary
distances are complied with.
