Viessmann TectoCell Standard Plus 80 User Manual

7
Assembly
5777744-03 GB Subject to technical changes!
4.4 Assembling a mounting frame
(without oor)
NOTE
Damage due to improper mount-
ing!
f Before drilling, make sure that any
moisture barriers which may be laid
on-site in screed are not damaged.
f Make sure that no dowel holes
are under the cam locks of the ele-
ments.
f Make sure that the sealing lip is
correctlyseatedontheooron-site.
L
Thanks to their special design, the plastic U-proles
seal all the way down to the oor after assembly.
Â

ScrewU-prolestoooroftheinstallationspaceat
the intended position.
 Note the position of the door.
 PlacewallelementsintoU-proles.
 RivetorscrewwallelementswithU-proles.
 Make sure that the wall elements are perpendicular.
Door element without oor
L
Door element without oor is delivered with securing
for transportation and without door frame heating.
 Remove the door element’s securing for transport
before installation.
4.3 Level oor
4.3.1
Room with oor ventilation
L
Rooms with oor ventilation: Room temperature below
-5 °C.
 Iftheooronsiteisnotevenornothorizontal,level
the height of the bottom ventilation panel:
 with adjustment plates
 Lay bottom ventilation panel loosely at distances of
200–300mm(clearspace).
 Begin levelling at the highest point.
 Make sure that the element joints (1)arecentred
during assembly and that the outsides of the ele-
ments (2)arelyingwiththeirfullsurfacesonthe
bottom ventilation panels.
4.3.2 Room without oor ventilation
 Iftheooron-siteisunevenornothorizontal,adjust
its height with adjustment plates.
