Assembly
5777744-03 GB Subject to technical changes!
 Inthecaseofoorelements(2)with1and2-side
connection,lltheconnectionpoint(3)withthe
enclosed sealant during assembly.
 Donotputanyloadontheoorelementstobeas-
sembled during tensioning.
 Makesurethattheoorelementstobeassembled
can move freely.
Â
Pushoorelements(4)together.
 Tighten eccentric cam lock (5)ontheexterior.
 Ifnecessary,pushtheopposingsideoftheoorele-
ment with a pry bar.
 Makesurethattheoorelementsarenotdamaged.
 Tighten the eccentric cam lock on the opposing
exterior side.
 Tighten interior eccentric cam locks.
4.5 Assembling room elements
Connect room elements as follows:
 Activate eccentric cam locks from inside of room.
First, only operate the centre locks to enable the
alignment of the walls.
 Check whether the room elements’ eccentric cam
locks can be opened by turning left with Allen key.
 Make sure that the room elements are not more
than 12 mm apart from one another.
 Push room elements together and close eccentric
cam locks by turning right.
4.6 Assembling oor elements
L
Floor elements with stainless steel top plate are t with
joint tape on the overlapping on the spring side.
 Makesurethatthereisnoprotectivelmonthejoint
tape.
 Make sure that the joint tape (1)arenotdamaged
during assembly.
