Viessmann VITOCONNECT 100 - Installation and Commissioning Sequence; Overall Process Overview

10
Sequence Responsibility Page
Installation
1 Check system requirements. Heating contractors
IT expert
8
2 Fit the wall mounting bracket for the
Vitoconnect 100.
Heating contractors
System user
10
3 Connect Vitoconnect 100 to heat source. Heating contractors
System user
11
4 Insert Vitoconnect 100 into wall mounting bracket. Heating contractors
System user
10
5 Connect power supply. Heating contractors
System user
11
Commissioning
6 Check network settings. IT expert 13
7 Register user and set up heating system. Heating contractors
System user
13
Installing the wall mounting bracket
1.
3.
2.
Fig. 2
Installation sequence
Overview of the installation and commissioning process
5785665
Installation
