17
Vitodens 100-W, type B1HA and B1KA, Vitodens 111-W
Rated heating output kW 26.0 26.0 30.0 35.0
System size 60/100 m 15 15 15 15
System size 80/125 m 25 20 20 20
Vitodens 200-W, 222-F and 242-F
Rated heating
output
kW 13 19 26 35 45 60 80 100
System size
60/100
m 20 20 20 15 — — — —
System size
80/125
m 25 25 25 25 20 15 — —
System size
100/150
m — — — — 25 20 20 20
Note
For alternative system sizes, a bal-
anced flue adaptor is required.
The following components are taken
into consideration for the maximum flue
lengths:
■ Balanced flue connection pipe 0.5 m
long
■ 1 balanced flue bend 87° and 1 sup-
port bend 87°
or
■ 2 balanced flue bends 45° and 1 sup-
port bend 87°
Subtract other bends, tees and straight
lengths from the maximum length using
the following values:
■ Balanced flue connection pipe 0.5 m
long: 1 m
■ Balanced flue connection pipe 1 m
long: 2 m
■ Balanced flue bends 45°: 0.5 m
■ Balanced flue bends 87°: 1 m
■ Balanced flue inspection tee: 1.5 m
Routing through a shaft
(cont.)
5780 223 GB
