Viessmann WB1A007 Installation Instructions

19
Maximum flue length
Vitodens 100-W, type B1HA and B1KA, Vitodens 111-W
Rated heating output kW 19 26.0 30.0 35.0
System size 60 m 15 15 20 20
System size 80 m 20 20 20 20
Note
For system size 80, an adaptor is
required.
Vitodens 200-W, 222-F and 242-F
Rated heating
output
kW 13 19 26 35 45 60 80 100
System size 60 m 20 20 20 15 — — — —
System size 80 m 25 25 25 25 20 15 — —
System size 100 m — — — — 25 20 20 20
The following components are taken
into consideration for the maximum flue
lengths:
■ Connection pipe 0.5 m long
■ 1 flue bend 87° and 1 support bend
87°
or
■ 2 flue bends 45° and 1 support bend
87°
Subtract other bends, tees and straight
lengths from the maximum length using
the following values:
■ Connection pipe 0.5 m long: 0.5 m
■ Connection pipe 1 m long: 1 m
■ Flue bend 45°: 0.3 m
■ Flue bend 87°: 0.5 m
■ Inspection tee: 0.3 m
Open flue operation with combustion air supply via interconnected rooms
Only possible with system sizes 60 and
80.
The connection piece to the shaft is
constructed as part of the balanced flue
system. The combustion air is drawn
from the room via an opening immedi-
ately by the chimney entry (air inlet
adaptor).
An adequate combustion air supply, as
specified by the TRGI 2008, must be
ensured inside the room by means of
an interconnected combustion air sup-
ply:
■ Minimum volume of the interconnec-
ted rooms, 4 m
3
per kW rated heating
output
■ Vents in the connecting doors min.
150 cm
2
Routing through a shaft
(cont.)
5780 223 GB
