Please note

Ensure the specified mini-

mum lengths above the roof

are observed.

Never trim roof outlets

above the roof.

Roof outlet

■ Use universal tiles or air vent tiles

with pipe outlets.

■ Position balanced flue slide cou-

pling

underneath the roof out-

let.

■ Install pipe outlets for Klöber or

universal roof tiles in accordance

with manufacturer's instructions.

■ Position the roof outlet onto the

roof tiles from above.

■ Connect the external wall pipe

from below.

Elbow in the external routing for

a short roof overhang

■

Elbow with 45° bend qR: Fit bal-

anced flue inspection piece

■

Elbow with 30° bend qR: Bal-

anced flue inspection piece

not required.

■

Fit external wall terminal qE

Routing over an external wall

(cont.)
